Technical Specifications:

• Input Primary Source Voltage : 360-460 / 340-460 / 295-465
• Output Voltage Regulation : 400 / 415 V± 1%
• Average Correction Rate : 70 V/Sec
• Total Harmonic Distortion : Nil
• Effect of Load Power Factor : Nil (On O/P Voltage)
• Efficiency : >98%
• Duty Cycle : Continuous
• Cooling : Air / Oil Cooled
• Overload Capacity : 120% for few sec.
• Electronic protection : Output under / Over voltage trip & Over load
• Normal operating Temperature : 0 - 45 deg C
• Type : Unbalanced
• Drive Mode : Automatic (or) Manual
• Optional Accessories : EMI surge Suppressor, Ammetter, Phase Reversal Protection, By-pass switch, Cutoff signal for ACB / OCB
